Onkyo PR-SC5509 User Manual

6
En
Features
Processing
• THX Ultra2 Plus
*1
Certified
• Incorporates Qdeo™
*2
technology for HDMI Video
Upscaling (to 4K Compatible)
•HQV
®
*3
-Vida Video Processing with 1080p Video
upscaling of All Video Sources via HDMI
• HDMI (Audio Return Channel, 3D, DeepColor,
x.v.Color
*4
, Lip Sync, DTS-HD Master Audio
*5
,
DTS-HD High Resolution Audio, Dolby TrueHD
*6
,
Dolby Digital Plus, DSD and Multi-CH PCM)
• Dolby TrueHD
*6
and DTS-HD Master Audio
*5
• Dolby Pro Logic IIz
*6
and Audyssey DSX™
*7
•DTSNeo:X
*5
• Non-Scaling Configuration
• A-Form Listening Mode Memory
• Direct Mode
• Pure Audio Mode
• Music Optimizer
*8
for Compressed Digital Music files
• High-Performance 192 kHz/32-Bit D/A Converters
• Powerful and Highly Accurate 32-bit Processing DSP
• Jitter Cleaning Circuit Technology
• DSD Direct for Super Audio CD
Connections
• Balanced XLR stereo input
• Balanced XLR 9.2-channel preouts, with front bi-
amping capability
•8HDMI
*9
Inputs (1 on front panel) and 2 Outputs
• Onkyo p for System Control
• 7 Digital Inputs (4 Optical/3 Coaxial)
• Component Video Switching (3 Inputs/2 Outputs)
• Universal Port for the Dock for iPod
®
/iPhone
®
*10
/
HD Radio™
*11
tuner module (North American
models)/DAB+ tuner module (European and Asian
models)
• Analog RGB Video Input (D-sub 15) for PC
• Internet Radio Connectivity (SiriusXM Internet
Radio/vTuner/Last.fm/Pandora/Rhapsody/Slacker/
Mediafly/Napster/Spotify)
*
Services available may vary depending on the region.
• 2 Independent Subwoofer Pre Outs
• Zone 2 and 3 Preouts
• Network Capability for Streaming Audio Files
*12
• 2 USB Inputs
*
(Front/Rear) for Memory Devices and
iPod
®
/iPhone
®
*10
models (Enables Display of Album
Artwork)
*
Only front-panel USB input is compatible with iPod/iPhone.
Miscellaneous
• 40 AM/FM Presets
•Dolby Volume
*6
• Audyssey MultEQ
®
XT32
*7
to correct room acoustic
problems
• Audyssey Dynamic EQ
®
*7
for loudness correction
• Audyssey Dynamic Volume
®
*7
to maintain optimal
listening level and dynamic range
• Crossover Adjustment
(40/45/50/55/60/70/80/90/100/110/120/130/150/200 Hz)
• A/V Sync Control Function (up to 800 ms)
• Auto Standby Function
• On-Screen Display via HDMI
• Bi-Directional Preprogrammed (with onscreen display
setup) RI-Compatible Learning Remote with 4 Activities
and Mode-Key LEDs
• ISF (Imaging Science Foundation) Video Calibration
•VLSC
*13
(Vector Linear Shaping Circuitry) for All
Channels

Onkyo PR-SC5509 Specifications

General

Receiver type	Surround
Input sensitivity	200 mV
Audio output channels	9.2 channels
Signal-to-Noise Ratio (SNR)	110 dB
Total Harmonic Distortion (THD)	0.05 %
Power output per channel (20-20KHz@8 Ohm)	- W
HDMI in	8
AC (power) in	Yes
Composite video in	5
USB ports quantity	2
S-Video inputs quantity	4
Multichannel audio input type	RCA
Component video (YPbPr/YCbCr) in	3
Component video (YPbPr/YCbCr) out	1
Connectivity technology	Wired
Ethernet LAN	No
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	40
Display	-
Product color	Black
Audio decoders	Dolby TrueHD, DTS-HD Master Audio
Apple docking compatibility	iPhone, iPod
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	110 W

Weight and Dimensions

Depth	453.5 mm
Width	435 mm
Height	198.5 mm
Weight	14000 g
