Onkyo PR-SC5509 User Manual

97
En
The following tables show how video signals at different resolutions are output by the AV controller.
NTSC/PAL
✔: Output
*1
Available resolutions: [640 × 480 60 Hz], [800 × 600 60 Hz], [1024 × 768 60 Hz], [1280 × 1024 60 Hz]
*2
Available resolutions: [3840 × 2160 24/25/30 Hz]
*3
The output is limited to 480p/576p for an effective signal in the effect of copy protect.
*4
PC IN (Analog RGB) input signal is output at 720p resolution when you select “Analog” in the “Monitor Out” setting
(➔ page 49) and “Through” in the “Resolution” setting (➔ page 49).
*
The on-screen menus and superimposed menus are displayed via HDMI OUT MAIN.
Video Resolution Chart
HDMI
4K
*2
1080p/24 1080p 1080i 720p 480p/576p 480i/576i
HDMI 1080p ✔✔✔
1080i ✔✔✔✔✔
720p ✔✔✔✔✔
480p/576p ✔✔✔✔✔✔
480i/576i ✔✔✔✔✔✔✔
Component 1080p ✔✔✔
1080i ✔✔✔✔✔
720p ✔✔✔✔✔
480p/576p ✔✔✔✔✔✔
480i/576i ✔✔✔✔✔✔✔
S-Video
Composite
480i/576i ✔✔✔✔✔✔✔
PC IN (Analog RGB)
*1
✔✔✔✔✔✔
Component S-Video
Composite
1080p 1080i 720p 480p/576p 480i/576i 480i/576i
HDMI 1080p
1080i
720p
480p/576p
480i/576i
Component 1080p ✔
1080i ✔✔
720p ✔✔
480p/576p
✔
*3
✔
*3
✔
480i/576i
✔
*3
✔
*3
✔✔
S-Video
Composite
480i/576i
✔
*3
✔
*3
✔✔✔
PC IN (Analog RGB)
*1
✔
*4
✔
*4
✔
*4
Output
Input
Output
Input

Onkyo PR-SC5509 Specifications

General

Receiver type	Surround
Input sensitivity	200 mV
Audio output channels	9.2 channels
Signal-to-Noise Ratio (SNR)	110 dB
Total Harmonic Distortion (THD)	0.05 %
Power output per channel (20-20KHz@8 Ohm)	- W
HDMI in	8
AC (power) in	Yes
Composite video in	5
USB ports quantity	2
S-Video inputs quantity	4
Multichannel audio input type	RCA
Component video (YPbPr/YCbCr) in	3
Component video (YPbPr/YCbCr) out	1
Connectivity technology	Wired
Ethernet LAN	No
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	40
Display	-
Product color	Black
Audio decoders	Dolby TrueHD, DTS-HD Master Audio
Apple docking compatibility	iPhone, iPod
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	110 W

Weight and Dimensions

Depth	453.5 mm
Width	435 mm
Height	198.5 mm
Weight	14000 g
