Onkyo TX-NR696-S User Manual

36
Front Panel≫ Rear Panel≫ Remote≫
Contents
≫
Connections
≫
Playback
≫
Setup
≫
Speaker combinations
• Up to two powered subwoofers can be connected in either combination.
(North American and Taiwanese models)
Speaker Channels FRONT CENTER SURROUND
SURROUND
BACK
HEIGHT Bi-AMP
ZONE 2
(ZONE SPEAKER)
2.1 ch
(*1) (*1)
3.1 ch
(*1) (*1)
4.1 ch
(*1) (*1)
5.1 ch
(*1) (*1)
6.1 ch
(*2)
7.1 ch
(*2)
2.1.2 ch
(*3) (*1) (*4) (*1)
3.1.2 ch
(*3) (*1) (*4) (*1)
4.1.2 ch
(*5)
5.1.2 ch
(*5)
(*1) You can select either Bi-AMP or ZONE SPEAKER.
(*2) When audio is being output from the ZONE SPEAKER, surround back speakers cannot play audio.
(*3) Connect the height speakers to the SURROUND terminals.
(*4) Connect the Bi-Amp speakers to the HEIGHT terminals.
(*5) When audio is being output from the ZONE SPEAKER, height speakers cannot play audio.

Onkyo TX-NR696-S Specifications

General

THX-certified	THX Select
3D	Yes
Supported graphics resolutions	3840 x 2160
HDCP version	2.2
Apple docking	-
Product color	Silver
Audio decoders	DTS Virtual:X, DTS-HD Master Audio, DTS:X, Dolby Atmos, Dolby Surround, Dolby TrueHD
Volume control	Rotary
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	40
Internet radio services supported	Deezer, Spotify, Tidal, TuneIn
Receiver type	Surround
Output impedance	470 Ω
Input sensitivity	200 mV
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	106 dB
Total Harmonic Distortion (THD)	0.08 %
Dynamic power per channel (3 Ohm)	240 W
Dynamic power per channel (4 Ohm)	210 W
Dynamic power per channel (8 Ohm)	120 W
Power output per channel (1KHz@6 Ohm)	175 W
Power output per channel (20-20KHz@8 Ohm)	- W
Audio formats supported	AIFF, ALAC, DSD, FLAC, WAV
HDMI in	7
Digital audio optical in	1
Headphone connectivity	6.3 mm
Number of HDMI outputs	2
Phono inputs (RCA)	4
Connectivity technology	Wired & Wireless
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.15 W
Power consumption (typical)	570 W
Package depth	468 mm
Package width	534 mm
Package height	265 mm
Package weight	12500 g
Optical drive included	No

Weight and Dimensions

Depth	379.5 mm
Width	435 mm
Height	173.5 mm
Weight	10000 g
