Onkyo TX-NR757 User Manual

15
> Before start > Hookup > Setup > Playback > Part Names > Advanced Manual
Troubleshooting | Appendix
OR
CD
2
1
Turntable
1 Digital optical cable, 2 Analog audio cable
if you have:
Audio Components
Example of a connection with an audio component.
Connect a CD player using a digital optical cable or
analog audio cable. You can also connect a turntable that
has an MM-type cartridge to the PHONO jack.
0 If the turntable has a built-in audio equalizer, connect it
to an AUDIO IN jack other than the PHONO jack.
Further, if the turntable uses an MC type cartridge,
install an audio equalizer compatible with the MC type
cartridge between the unit and the turntable, then
connect to any AUDIO IN jack other than the PHONO
jack.
If the turntable has a ground wire, connect it to the GND terminal
of this unit.

Onkyo TX-NR757 Specifications

General

Audio Channels	7.2
HDMI Outputs	2
Dolby Atmos	Yes
DTS:X	Yes
Wi-Fi	Yes
Bluetooth	Yes
Multi-room Capability	Yes
4K Ultra HD Pass-through	Yes
AirPlay	Yes
Phono Input	Yes
Zone 2	Yes
Frequency Response	10 Hz - 100 kHz
Power Output	100W per channel (8 ohms, 20Hz-20kHz, 0.08% THD, 2 channels driven)
HDMI Inputs	8
HDR Support	Yes (HDR10, Dolby Vision)
THX Certified	Yes
THD	0.08%
Inputs/Outputs	USB Port, Ethernet Port
Supported Audio Formats	Dolby Atmos, DTS:X, Dolby TrueHD, DTS-HD Master Audio
Video Support	HDR10, Dolby Vision
Dimensions	435 x 381 x 180 mm
