Onkyo TX-NR757 User Manual

11
> Before start > Hookup > Setup > Playback > Part Names > Advanced Manual
Troubleshooting | Appendix
Step3: Connect the TV
TV
1
HDMI IN (ARC)
1 HDMI cable
if you have:
ARC TV
This unit is connected between your TV and AV
components. If you connect two or more AV components,
you can select the video displayed on the TV and the
audio output from this unit by changing the input selector.
Shown here are the connections for a TV that supports
the ARC (Audio Return Channel) feature. By connecting
with a single HDMI cable, you can not only output the
video input to this unit to the TV, but you can also play the
sound from the TV through this unit.
Choose an HDMI IN jack on the TV that supports ARC
when connecting.
Another TV or projector can be connected to the HDMI OUT SUB
jack. This jack does not support ARC. For details about how to
output video from the HDMI OUT SUB jack (P22)
Setup
0 Settings are required to use the ARC function.
Select "Yes" in "5. Audio Return Channel" (
 P21)
in the Initial Setup.
0 Please refer to the TV's operation manual for
directions on connections and setup for the TV.

Onkyo TX-NR757 Specifications

General

Audio Channels	7.2
HDMI Outputs	2
Dolby Atmos	Yes
DTS:X	Yes
Wi-Fi	Yes
Bluetooth	Yes
Multi-room Capability	Yes
4K Ultra HD Pass-through	Yes
AirPlay	Yes
Phono Input	Yes
Zone 2	Yes
Frequency Response	10 Hz - 100 kHz
Power Output	100W per channel (8 ohms, 20Hz-20kHz, 0.08% THD, 2 channels driven)
HDMI Inputs	8
HDR Support	Yes (HDR10, Dolby Vision)
THX Certified	Yes
THD	0.08%
Inputs/Outputs	USB Port, Ethernet Port
Supported Audio Formats	Dolby Atmos, DTS:X, Dolby TrueHD, DTS-HD Master Audio
Video Support	HDR10, Dolby Vision
Dimensions	435 x 381 x 180 mm
