Onkyo TX-NR787 User Manual

137
Front Panel≫ Rear Panel≫ Remote≫
Contents
≫
Connections
≫
Playback
≫
Setup
≫
Initial Setup with Auto Start-up Wizard
When you turn the unit on for the rst time after purchase, the Initial Setup screen
is automatically displayed on the TV to allow you to make settings required for
startup using simple operations following on-screen guidance.
1. Switch the input of the TV to the input connected to the unit.
2. Put batteries into the remote controller of this unit.
3. Press on the remote controller to turn the unit on.
4. Select the item with the cursors of the remote controller, and press ENTER to
conrm your selection. To return to the previous screen, press .
MEMORY
/ / /
ENTER
CLEAR
Operations
Inputs
TV
HDMI 1
HDMI 2
HDMI 3
TV
INPUT
TV’s REMOTE

Onkyo TX-NR787 Specifications

General

Channels	9.2
THD+N (Total Harmonic Distortion + Noise)	0.08%
Total Harmonic Distortion	0.08%
Input Sensitivity and Impedance (Line)	200 mV/47 kΩ
Signal to Noise Ratio (Line)	106 dB
Speaker Impedance	4 - 16 ohms
HDMI Outputs	2
Audio Return Channel (ARC)	Yes
Digital Audio Inputs	2 Optical, 1 Coaxial
Analog Audio Inputs	5
Phono Input	Yes
Zone 2 Audio Output	Yes
Zone 3 Audio Output	Yes
Speaker Outputs	9
Subwoofer Outputs	2
USB Input	1 (Front)
Ethernet	Yes
Wi-Fi	Yes
Bluetooth	Yes
Radio Tuner	FM/AM
Surround Sound Processing	Dolby Atmos, DTS:X
Audio Decoders	Dolby TrueHD, DTS-HD Master Audio
Standby Power Consumption	0.15 W
Input Sensitivity and Impedance (Phono MM)	3.5mV/47kΩ
Frequency Response	10 Hz - 100 kHz
Signal to Noise Ratio (Phono MM)	80dB
HDMI Inputs	7
HDMI Support	4K/60Hz, HDR10, Dolby Vision, HLG, HDCP 2.2
USB Port	Yes
Streaming Services	Spotify, Tidal, TuneIn
FM Tuning Range	87.5MHz-108MHz
Video Support	4K/60Hz, HDR10, Dolby Vision, HLG
Dimensions (W x H x D)	435 x 177 x 379.5mm
AM Tuning Range	530 kHz-1, 710 kHz
