Onkyo TX-NR787 User Manual

65
Front Panel≫ Rear Panel≫ Remote≫
Contents
≫
Connections
≫
Playback
≫
Setup
≫
AirPlay
®
By connecting this unit to the same network as iOS devices, such as iPhone
®
, iPod touch
®
and iPad
®
, you can enjoy music les on iOS devices wirelessly.
• Update the OS version on your iOS device to the latest version.
• Depending on the iOS version, operation screens or operation procedures on the iOS device may be di󰀨erent. For details, refer to the operating instructions for the iOS device.
Basic Operations
1. Connect the iOS device to the access point where this unit is connected via
network.
2. Tap the AirPlay icon on the play screen of the music play application on the
iOS device, and select this unit from the displayed devices.
3. Play the music le on the iOS device.
• When "5. Hardware" - "Power Management" - "Network Standby" is set to "O󰀨"
in the Setup menu, turn this unit on manually, and press NET on the remote
controller. In the factory default setting, the Network Standby function
( p126) is set to On.
• Due to the characteristics of AirPlay wireless technology, the sound produced
on this unit may slightly be behind the sound played on the AirPlay-enabled
device.
You can also play the music les on a PC with iTunes (Ver. 10.2 or later)
equipped. Conrm that this unit and the PC are connected to the same network
beforehand. Then, press NET on this unit. Next, click the AirPlay icon in
iTunes, select this unit from the displayed devices, and start play of a music le.
Onkyo TX-NR787 XXXXXX
iPhone
Wi-Fi
e.g., iOS 10

Onkyo TX-NR787 Specifications

General

Channels	9.2
THD+N (Total Harmonic Distortion + Noise)	0.08%
Total Harmonic Distortion	0.08%
Input Sensitivity and Impedance (Line)	200 mV/47 kΩ
Signal to Noise Ratio (Line)	106 dB
Speaker Impedance	4 - 16 ohms
HDMI Outputs	2
Audio Return Channel (ARC)	Yes
Digital Audio Inputs	2 Optical, 1 Coaxial
Analog Audio Inputs	5
Phono Input	Yes
Zone 2 Audio Output	Yes
Zone 3 Audio Output	Yes
Speaker Outputs	9
Subwoofer Outputs	2
USB Input	1 (Front)
Ethernet	Yes
Wi-Fi	Yes
Bluetooth	Yes
Radio Tuner	FM/AM
Surround Sound Processing	Dolby Atmos, DTS:X
Audio Decoders	Dolby TrueHD, DTS-HD Master Audio
Standby Power Consumption	0.15 W
Input Sensitivity and Impedance (Phono MM)	3.5mV/47kΩ
Frequency Response	10 Hz - 100 kHz
Signal to Noise Ratio (Phono MM)	80dB
HDMI Inputs	7
HDMI Support	4K/60Hz, HDR10, Dolby Vision, HLG, HDCP 2.2
USB Port	Yes
Streaming Services	Spotify, Tidal, TuneIn
FM Tuning Range	87.5MHz-108MHz
Video Support	4K/60Hz, HDR10, Dolby Vision, HLG
Dimensions (W x H x D)	435 x 177 x 379.5mm
AM Tuning Range	530 kHz-1, 710 kHz
