Onkyo TX-NR900

F/C ch. driver circuit PC board (NAAF-7690-1A/1B/1C/1D/1E/1F)
CIRCUIT NO. PART NO. DESCRIPTION
Transistors
Q5000~Q5002 2215896, * KTC3200-BL,
Q5010~Q5012 2210755, * 2SC1775A-E,
2210756 or * 2SC1775A-F or
2211733 * 2SC1845-E
Q5020~Q5022 2215896, KTC3200-BL,
2210755, 2SC1775A-E,
2210756 or 2SC1775A-F or
2211733 2SC1845-E
Q5030~Q5032 2215844, KTA1024-Y,
Q5040~Q5042 2211353, 2SA949-O,
2211354 or 2SA949-Y or
2215843 KTA1024-O
Q5050~Q5052 2202094 or 2SA1360-Y
2202093 2SA1360-O
Q5080~Q5082 2202104 or 2SC3423-Y or
2202103 2SC3423-O
Diodes
D5000~D5002 224470562 MTZJ5.6B
Capacitors
C5000~C5002 393362207 22uF,35V, Elect.
C5010,C5011 374721015 100pF+/-10%,50V,Plastic
C5012 374722215 220pF+/-10%,50V,Plastic
C5040~C5042 393342217 220uF,16V, Elect.
C5050~C5052 394681007 10uF,50V, Elect.
C5070~C5072 394691007 10uF,100V, Elect.
C5080~C5082 394672207 22uF,63V, Elect.
C5090~C5092 394684707 47uF,50V, Elect.
C5100~C5102 374721015 100pF+/-10%,50V,Plastic
C5120~C5122 394691017S 100uF,100V, Elect.
C5130~C5132 394691017S 100uF,100V, Elect.
Resistors
R5130~R5132 415478214 820ohm+/-5%,1/4W,NF carbon
R5140~R5142 415478214 820ohm+/-5%,1/4W,NF carbon
R5150~R5152 443521034 10kohm+/-5%, 1/2W, Metal oxide
R5160~R5162 415471024 1kohm+/-5%,1/4W,NF carbon
R5170~R5172 415478214 820ohm+/-5%,1/4W,NF carbon
R5180~R5182 415473304 33ohm+/-5%,1/4W,NF carbon
R5230~R5232 415471504 15ohm+/-5%,1/4W,NF carbon
R5240~R5242 415471504 15ohm+/-5%,1/4W,NF carbon
R5280~R5282 443521034 10kohm+/-5%, 1/2W, Metal oxide
R5300~R5302 415476804 68ohm+/-5%,1/4W,NF carbon
R5330~R5332 415476804 68ohm+/-5%,1/4W,NF carbon
Terminals
P5100,P5101 25060302 NTM-1P233(M1969)
P6907 260224 CP-1S,Clip
Sockets
P6000A~P6002
A
25052287 NSCT-4P2184
P6010A 25052289 NSCT-6P2186
P6011A,P6012A 25052287 NSCT-4P2184
Plug
P6401 25055042 NPLG-3P32
Radiators
Q5050A~Q5052
A
27160517 RAD-177
Screws
Q5050B~Q5052
B
838430107 3TTB+10S(BC),Self-tapping
Q5080B~Q5082
B
838430107 3TTB+10S(BC),Self-tapping
Primary circuit PC board (NAPS-7691-1A/1B/1C/1D/1E/1F)
CIRCUIT NO. PART NO. DESCRIPTION
Transistor
Q921 2215864, KTC3199-GR,
2212115, 2SC2458-GR,
2213284 or 2SC1740S-R or
2213285 2SC1740S-S
Diodes
D921~D924 22380260, RL1N4003,
22380032 or 1SR139-100 or
22380035 GP104003E
D925 223163, 1SS133,
223205 or 1SS270A or
223222 WG713A
Power transformer
T902 2301661 ! NPT-1456D <D>
T902 2301662 ! NPT-1456P <P/A>
T902 2301663 ! NPT-1456DG <T/R/GT>
Capacitors
C901 3500196S ! RE275V-103M,IS
C902 3300030 ! DE1307E472M-KH <O>
C922 394662217 220uF,35V, Elect.
Resistors
R901 4000206S or ! RD1/2SPH-3.3M or
R901 or 431533355 ! RC1/2GFKUL-3.3M <D>
R924 443528204 82ohm+/-5%, 1/2W, Metal oxide
Relay
RL901 25065584 or ! NRL-1P10A-DC12-140 or
25065516 ! NRL-1P10A-DC12-097
Switch
S902 25065437 ! NSS-22157P <T/R>
Fuses
F901 252196 ! 12A-UL/T-314, Fuse <D/T/R>
F902 252078, ! 5A-SE-EAK,
252244 or ! 5A-SE-TL250V or
252278 ! 5A-SE-TL250V, Fuse <O>
F903 252075, ! 2.5A-SE-EAK,
252241 or ! 2.5A-SE-TL250V or
252275 ! 2.5A-SE-TL250V, Fuse <O>
Fuse holders
F901A,F901B 250113 ! SN5051 <D/T/R>
F902A,F902B 25052133 ! NSCT-1P2031 <O>
F903A,F903B 25052133 ! NSCT-1P2031 <O>
AC outlet
P902 25051126 ! NSCT-4P913 <D>
P902 25051125 ! NSCT-4P912 <P/T/GT>
P902 25052115 ! NSCT-2P2013 <A>
P902 25052664 ! NSCT-2P2560 <R>
Socket
JL931B 25050267 NSCT-3P95
Plugs
P901A 25055675 or ! NPLG-2P631 or
P901Aor 25056028 ! NPLG-2P0978 <D/A>
P911 25055675 or NPLG-2P631 or
P911 or 25056028 NPLG-2P0978
P912 25055675 or NPLG-2P631 or
P912 or 25056028 NPLG-2P0978 <T/R/GT>
Fuse labels
F901C 29362325 12A/250V <D/T/R>
F902C 29361938 T5AL250V <O>
CAUTION: Replacement for transistor of mark *, if necessary
must be made from the same beta group (H
FE) as
the original type.
NOTE: THE COMPONENTS IDENTIFIED BY MARK !
ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH
PART NUMBER SPECIFIED.
Note:
<D>: 120V model only
<P>: European model only
<T>: Worldwide model only
<O>: Except 120V model
<GT>: 220-230 V model only
<A>: Australian model only
<R>: Chinese model only
TX-NR900/E
PRINTED CIRCUIT BOARD-PARTS LIST 2
