838430107 3TTB+10S(BC),Self-tapping
Surround ch. driver circuit PC board (NAAF-7707-1A/1B)
CIRCUIT NO. PART NO. DESCRIPTION
Transistors
Q5003~Q5006 2215896, * KTC3200-BL,
Q5013~Q5016 2210755, * 2SC1775A-E,
2210756 or * 2SC1775A-F or
2211733 * 2SC1845-E
Q5023~Q5026 2215896, KTC3200-BL,
2210755, 2SC1775A-E,
2210756 or 2SC1775A-F or
2211733 2SC1845-E
Q5033~Q5036 2215844, KTA1024-Y,
Q5043~Q5046 2211353, 2SA949-O,
Q5053~Q5056 2211354 or 2SA949-Y or
2215843 KTA1024-O
Q5083~Q5086 2215854, KTC3206-Y,
2211633, 2SC2229-O,
2211634 or 2SC2229-Y or
2215853 KTC3206-O
Diodes
D5003~D5006 224470562 MTZJ5.6B
Capacitors
C5003~C5006 393381007 10uF,50V, Elect.
C5013~C5016 374722215 220pF+/-10%,50V,Plastic
C5043~C5046 393341017 100uF,16V, Elect.
C5053~C5056 394681007 10uF,50V, Elect.
C5073~C5076 394691007 10uF,100V, Elect.
C5083~C5086 394672207 22uF,63V, Elect.
C5093~C5096 394684707 47uF,50V, Elect.
C5103~C5106 374721015 100pF+/-10%,50V,Plastic
C5123~C5126 394694707 47uF,100V, Elect.
C5133~C5136 394694707 47uF,100V, Elect.
Resistors
R5133~R5136 415478214 820ohm+/-5%,1/4W,NF carbon
R5143~R5146 415478214 820ohm+/-5%,1/4W,NF carbon
R5153~R5156 443521034 10kohm+/-5%, 1/2W, Metal oxide
R5163~R5166 415471024 1kohm+/-5%,1/4W,NF carbon
R5173~R5176 415478214 820ohm+/-5%,1/4W,NF carbon
R5183~R5186 415473304 33ohm+/-5%,1/4W,NF carbon
R5233~R5236 415471504 15ohm+/-5%,1/4W,NF carbon
R5243~R5246 415471504 15ohm+/-5%,1/4W,NF carbon
R5283~R5286 443521034 10kohm+/-5%, 1/2W, Metal oxide
R5303~R5306 415471014 100ohm+/-5%,1/4W,NF carbon
R5333~R5336 415471014 100ohm+/-5%,1/4W,NF carbon
Terminals
P5201,P5202 25060302 NTM-1P233(M1969)
CIRCUIT NO. PART NO. DESCRIPTION
Sockets
P6003A~P6006
25052287 NSCT-4P2184
Power supply PC board (NAPS-7708-1A/1B)
CIRCUIT NO. PART NO. DESCRIPTION
ICs
Q9401 222780185JRC NJM78M18FA
Q9411 222790185JRC NJM79M18FA
Q9421 222780053JRC NJM78L05A
Q9431 222780054JRC NJM7805FA
Q9441 222790054JRC NJM7905FA
Transistors
Q6901 2215864, KTC3199-GR,
2212115, 2SC2458-GR,
2213284 or 2SC1740S-R or
2213285 2SC1740S-S
Q9422 2202314 or 2SA1726-Y or
2202315 2SA1726-P
Q9501 2211644 2SA965-Y
Diodes
D9501,D9502A 22380285F, RS403M,
22380022F or RBV402 or
22380271F D3SBA20
D9506,D9507 22380260, RL1N4003,
22380032 or 1SR139-100 or
22380035 GP104003E
D9508 224472704 MTZJ27D
Capacitors
C9401,C9402 394561007 10uF,35V, Elect.
C9411,C9412 394561007 10uF,35V, Elect.
C9421,C9422 394561007 10uF,35V, Elect.
C9431,C9432 394561007 10uF,35V, Elect.
C9441,C9442 394561007 10uF,35V, Elect.
C9501~C9504 374723344 0.33uF+/-5%,50V,Plastic
C9505 394662227 2200uF,35V, Elect.
C9506 394661027 1000uF,35V, Elect.
C9507 394682217 220uF,50V, Elect.
C9508 394646827 6800uF,16V, Elect.
C9509 394651027 1000uF,25V, Elect.
C9510 394672217 220uF,63V, Elect.
C9513 374723344 0.33uF+/-5%,50V,Plastic
C9521~C9523 374722234 0.022uF+/-5%,50V,Plastic
Resistors
R9403 453530224 2.2ohm+/-5%, 1/2W, Metal
R9413 453530824 8.2ohm+/-5%, 1/2W, Metal
R9421~R9425 441620824 8.2ohm+/-5%, 1W, Metal oxide
R9431,R9433 441621004 10ohm+/-5%, 1W, Metal oxide
R9442,R9444 441622204 22ohm+/-5%, 1W, Metal oxide
R9506 415472204 22ohm+/-5%,1/4W,NF carbon
R9510 415470224 2.2ohm+/-5%,1/4W,NF carbon
R9521 453530334 3.3ohm+/-5%, 1/2W, Metal
Fuses
F9501,F9502 252160 or ! 2.5A-UL/T-237 or
252254 ! 2.5A-T/UL-ST2, Fuse <D>
252075, ! 2.5A-SE-EAK,
252241 or ! 2.5A-SE-TL250V or
252275 ! 2.5A-SE-TL250V, Fuse <O>
F9501A 29363313 ! T2.5AL1.6AL250V, Label, fuse <O>
F9503,F9504 252252 ! 1.6A-T/UL-ST2, Fuse <D>
252073, ! 1.6A-SE-EAK,
252239 or ! 1.6A-SE-TL250V or
252273 ! 1.6A-SE-TL250V, Fuse <O>
CAUTION: Replacement for transistor of mark *, if necessary
must be made from the same beta group (H
FE) as
the original type.
NOTE: THE COMPONENTS IDENTIFIED BY MARK !
ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH
PART NUMBER SPECIFIED.
Note:
<D>: 120V model only
<P>: European model only
<T>: Worldwide model only
<O>: Except 120V model
<GT>: 220-230 V model only
<A>: Australian model only
<R>: Chinese model only
TX-NR900/E
PRINTED CIRCUIT BOARD-PARTS LIST 5
