Onkyo TX-SR504E - Page 104

28/54 PAGE
PCB1
P6901 CRIMP AS CRIMP AS 1 2069925226UL
PCB1
P6902 CRIMP AS CRIMP AS 1 2069925189UL
PCB1
P6903 CRIMP AS CRIMP AS 1 20799163UL
PCB1
P6904 CRIMP AS CRIMP AS 1 20799164UL
PCB1
P6911 RETAINER (BUS) 1 27142022
PCB1
P7900 ST JACK LGY2502-0200FC 1 25045696
PCB1
P7902 PIN JACK NPJ-6PDWWWRRR561 1 25045779
PCB1
P7902 or PIN JACK NPJ-6PDBL159 (1) 25045300
PCB1
P7904 PIN JACK NPJ-6PDWWWRRR561 1 25045779
PCB1
P7904 or PIN JACK NPJ-6PDBL159 (1) 25045300
PCB1
P7905 PIN JACK NPJ-4PDWLRE642 1 25045866
PCB1
P7906 PIN JACK NPJ-4PDGNPT643 1 25045867
PCB1
P7908 PIN JACK NPJ-1PDP555 1 25045773
PCB1
F6901A FUSE HOL NSCT-1P2031 1 25052133
!
PCB1
F6901B FUSE HOL NSCT-1P2031 1 25052133
!
PCB1
F6902A FUSE HOL NSCT-1P2031 1 25052133
!
PCB1
F6902B FUSE HOL NSCT-1P2031 1 25052133
!
PCB1
J5500 PVC 1007#24 .2/7HAND B 1 --- NSP
PCB1
J5500 or PVC 1007#24 .2/7HAND R (1) --- NSP
PCB1
JL5502 JUMPER LEAD JL7 400 B 1 --- NSP, <DD, DC>
PCB1
JL5502A WIRE HOL NSCT-7P878 1 --- NSP, <DD, DC>
PCB1
JL6402 JUMPER LEAD JL3 300 B 1 --- NSP
PCB1
JL6402A WIRE HOL NSCT-3P874 1 25051087
PCB1
JL6600 JUMPER LEAD JL7 200 H 1 --- NSP
PCB1
JL6600A WIRE HOL NSCT-7P898 1 25051111
PCB1
JL6603 JUMPER LEAD JL9 200 H 1 --- NSP
PCB1
JL6603A WIRE HOL NSCT-9P900 1 25051113
PCB1
JL6604 JUMPER LEAD JL4 200 H 1 --- NSP
PCB1
JL6604A WIRE HOL NSCT-4P895 1 25051108
PCB1
JL6952 JUMPER LEAD JL4 150 H 1 --- NSP
PCB1
JL6952A WIRE HOL NSCT-4P895 1 25051108
PCB1
JL6952B WIRE HOL NSCT-4P895 1 25051108
PCB2
U05 DISPLAY PC BOARD (NADIS-8785-1A/ 1C / 1D / 1E/ 1F)
PCB2
U06 SWITCH PC BOARD (NADIS-1A/ 1C / 1D / 1E/ 1F)
PCB2
U07 POWER SUPPLY PC BOARD (NAPS-8787-1A/ 1C / 1D / 1E/ 1F)
PCB2
U08 TRANS SEC. TERMINAL PC BOARD (NAETC-8788-1A/ 1C / 1D / 1E/ 1F)
PCB2
U10 HEADPHONE JACK PC BOARD (NAETC-8790-1A/ 1C / 1D / 1E/ 1F)
PCB2
U13 OUTLET PC BOARD (NAETC-8793-1F) <Note> MGK Type only
PCB2
U14 VOLTAGE SELECTOR PC BOARD (NASW-8794-1C) <Note> MWT Type only
PCB2
PCB2
CIRCUIT NO
.
PART NAME DESCRIPTION Q'TY PART NO. (SN)
REMARKS
PCB2
U7041 REMO SENS NJL34H380A 1 241365
PCB2
Q7001 FL TUBE 16-BT-128GNYK 1 212258A
PCB2
Q7001A HOLDER (FL) 1 27191222B
