Onkyo TX-SR504E - Page 110

34/54 PAGE
PCB3
U19 XM DIGITAL TRANSCEIVER PC BOARD (NADG-8799-1A) (DD, DC Only)
PCB3
PCB3
CIRCUIT NO.
PART NAME DESCRIPTION Q'TY PART NO. (SN)
REMARKS
PCB3
U131 PHT.CP 2poinsMount TORX177L 1 24120127
PCB3
U131 or PHT CP 3 poins mount GPIFAV51RKF5 recieving 1 24120129
PCB3
U132 PHT CP 2poinsMount TORX177L 1 24120127
PCB3
U132 or PHT CP 3 poins Mount GPIFAV51RKF5 recieving (1) 24120129
PCB3
U133 PHTCP 2poinsMount TORX177L 1 24120127
PCB3
U133 or PHT CP 3 poins Mount GPIFAV51RKF5 recieving (1) 24120129
PCB3
Q131 IC 74HCU04F 1 222740046R2
PCB3
Q151 IC TC74VHC541FT(EKJ) 1 22274541E1R2TO
PCB3
Q151 or IC SN74AHC541PWR (1) 22274541IR2TI
PCB3
Q151 or IC TC74VHC541FT (1) 22274541ER2TO
PCB3
Q152 IC TC74HCT7007AF(EL_F) 1 222740077R2TO
PCB3
Q171 IC TC7WU04FU(TE12L_F) 1 22240935R2
PCB3
Q201 IC D707E001RFP250 1 22242309R3
PCB3
Q281 IC M12L16161A-7TG 1 22242278R3
PCB3
Q281 or IC IC42S16100 (1) 22242123R2
PCB3
Q281 or IC RMS116T(LF) (1) 22242340R3
PCB3
Q282 IC (DSP ROM) ES29LV400 1 222W0045R3
PCB3
Q301 IC CS42518-CQZR-D 1 22242229R2
PCB3
Q341 IC NJM4580M-D 1 22241448R2
PCB3
Q401 IC NJM4580M-D 1 22241448R2
PCB3
Q402 IC NJM4580M-D 1 22241448R2
PCB3
Q403 IC NJM4580M-D 1 22241448R2
PCB3
Q404 IC NJM4580M-D 1 22241448R2
PCB3
Q701 IC (MICROPROCESSOR) M30622MWP-B06 1 22242364R3
PCB3
Q710 IC S-812C56AUA-C3K 1 22242207R2
PCB3
Q741 IC SI8008TM 1 22242323R2
PCB3
Q742 IC BD7820 1 22242300R2
PCB3
Q762 IC TA48033AF(TE16L_NQ) 1 22278033DR2TO
PCB3
Q762 or IC BA33BC0FP (1) 22278033DR2RH
PCB3
Q762 or IC NJM2391DL1-33 (1) 22278033DR2JR
PCB3
Q2001 IC F2602E-01 1 22242266R2 <DD, DC>
PCB3
Q2002 IC AK4384ET 1 22242280R2 <DD, DC>
PCB3
Q2003 IC NJM4580M-D 1 22241448R2 <DD, DC>
PCB3
Q2004 IC TA48033AF(TE16L_NQ) 1 22278033DR2TO <DD, DC>
PCB3
Q2004 or IC BA33BC0FP (1) 22278033DR2RH <DD, DC>
PCB3
Q2004 or IC NJM2391DL1-33 (1) 22278033DR2JR <DD, DC>
PCB3
Q2005 IC 78L05(NJM78L05UA) 1 222780053R2JR <DD, DC>
PCB3
Q2006 IC TC74HCT7007AF(EL_F) 1 222740077R2TO <DD, DC>
PCB3
Q2007 IC TC74VHC541FT(EKJ) 1 22274541E1R2TO <DD, DC>
PCB3
Q2007 or IC SN74AHC541PWR (1) 22274541IR2TI <DD, DC>
PCB3
Q2007 or IC TC74VHC541FT (1) 22274541ER2TO <DD, DC>
PCB3
Q702 TR KRC104S 1 2216210R2
