Onkyo TX-SR504E - Page 77

1/54 PAGE
TX-SR504/504E/8450
<Note>
Parts marked by "NSP" are generally unavailable because
they are not in our Master Spare Parts List.
<Notes>
(B) : Black model
(S) : Silver model
(G) : Golden model
<DD> : TX-SR504 USA model
<DC> : TX-SR504 Canadian model
<WT> : TX-SR504 World wide model
<GR> : TX-SR504/8450 Chinese model
<504 GR> : TX-SR504 Chinese model
<8450 GR> : TX-SR8450 Chinese model
<GQ> : TX-SR504 Hong kong model
<GK> : TX-SR504 Korean model
<PP> : TX-SR504E European model
EXPLODED VIEW PARTS LIST
REF. NO. PART NAME DESCRIPTION Q'TY PART NO. (SN)
REMARKS
EV
A001 F BRACKET --- 1 27111442 (B)
EV
A001 F BRACKET --- 1 27111443 (G)
EV
A001 F BRACKET --- 1 27111444 (S)
EV
A002 SCREW 3TTB+8B(3CM)SR 5 801637
EV
A004 CUSHION --- 1 28141686
EV
A011 SCREW 3TTB+8B(3CM)SR 3 801637
EV
A012 SCREW 3TTB+8B(3CM)SR 2 801637
EV
A013 WIRE TIE BSK-1 7 260208
EV
A015 CHASSIS --- 1 --- NSP
EV
A016 SCREW 3TTB+8B(3CM)SR 1 801637
EV
A017 WIRE TIE BINDER(CLAMPER)UL 2 260258
EV
A018 HOLDER KGLS-22S 1 27190369
EV
A020 HOLDER KGLS-16RT 2 27190511
EV
A021 HOLDER HOLDER 4 27190991
EV
A022 HOLDER KGLS-10RT 1 27190428A
EV
A024 SCREW 3TTB+8B(3CM)SR 3 801637
EV
A025 HOLDER HOLDER 1 27190965
EV
A027 HOLDER HOLDER KGLS-18S 1 27190470
EV
A028 CLIP CS-1U 1 27255004
EV
A029 SCREW 3TTB+8B(3CM)SR 1 801637
EV
A030 SCREW 4TTC+8C(3BC) 4 830440089GR
EV
A031 SPACER --- 1 27270439
EV
A033 LABEL (PT) 1 29363379-1
EV
A035 HOLDER KGLS-14RT 1 27190524
EV
A037 BUSHING S-RELIEF #2271 1 27300750
!
NOTE : THE COMPONENTS IDENTIFIED BY THE MARK
! ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH PART
NUMBER SPECIFIED.
