Onkyo TX-SR504E - Page 86

10/54 PAGE
EV
U20 VIDEO PC board ass'y NAVD-8804-1A 1 1B126504-1A <DD, DC>
EV
U20 VIDEO PC board ass'y NAVD-8804-1C 1 1B126504-1C <WT>
EV
U20 VIDEO PC board ass'y NAVD-8804-1C 1 1B126504-1C <GR, GQ, GK>
EV
U20 VIDEO PC board ass'y NAVD-8804-1C 1 1B126504-1C <PP>
EV
U21 TUNER UNIT ENG06507QFUS 1 240156 <DD, DC>
EV
U21 or TUNER UNIT FAE385-A11US (1) 240152 <DD, DC>
EV
U21 TUNER UNIT FAE485-E12EX 1 240155 <WT>
EV
U21 TUNER UNIT FAE485-E12EX 1 240155 <GR>
EV
U21 TUNER UNIT ENG07506QFEX 1 240159 <GQ, GK>
EV
U21 or TUNER UNIT FAE485-E12EX (1) 240155 <GQ, GK>
EV
U21 TUNER UNIT FAE485-E11EU 1 240154 <PP>
TX-SR504/504E/8450
PC BOARD PARTS LIST
PCB1
U01 AMPLIFIER PC BOARD (NAAF-8779-1A/ 1K)
PCB1
U02 TRANS SEC. TERMINAL PC BOARD (NAPS-8780-1A/ 1K)
PCB1
U03 THERMAL SENSOR PC BOARD (NAETC-8781-1A/ 1K)
PCB1
PCB1
CIRCUIT NO
.
PART NAME DESCRIPTION Q'TY PART NO. (SN)
REMARKS
PCB1
Q5501 IC R2S15211FP 1 22242297R3
PCB1
Q5503 IC NJM4580M-D 1 22241448R2
PCB1
Q5630 IC NJM4580M-D 1 22241448R2
PCB1
Q5670 IC 78M12HF(NJM78M12FA) 1 222780125JRC
PCB1
Q5670 or IC 78M12HF(MPC78M12HF) (1) 222780125NEC
PCB1
Q5670 or IC 78M12(AN78M12F) (1) 222780125MAT
PCB1
Q5670A HEAT-SINK HEAT-SINK(RAD-68) 1 27160211
PCB1
Q5670B SCREW 3P+10FN(3BC) 1 82143010GR
PCB1
Q5671 IC 79M12HF(NJM79M12FA) 1 222790125JRC
PCB1
Q5671 or IC 79M12HF(MPC79M12HF) (1) 222790125NEC
PCB1
Q5671 or IC 79M12F(AN79M12F) (1) 222790125MAT
PCB1
Q5671A HEAT-SINK HEAT-SINK(RAD-68) 1 27160211
PCB1
Q5671B SCREW 3P+10FN(3BC) 1 82143010GR
PCB1
Q6380 IC LM61CIZ 1 22242212
PCB1
Q6380A RETAINER (PTH) 1 27141884-1
PCB1
Q5000 TR 2SC2240-BL(TPE2_F) 1 2211406
PCB1
Q5001 TR 2SC2240-BL(TPE2_F) 1 2211406
PCB1
Q5002 TR 2SC2240-BL(TPE2_F) 1 2211406
PCB1
Q5003 TR 2SC2240-BL(TPE2_F) 1 2211406
PCB1
Q5004 TR 2SC2240-BL(TPE2_F) 1 2211406
PCB1
Q5005 TR 2SC2240-BL(TPE2_F) 1 2211406
PCB1
Q5006 TR 2SC2240-BL(TPE2_F) 1 2211406
PCB1
Q5010 TR 2SC2240-BL(TPE2_F) 1 2211406
PCB1
Q5011 TR 2SC2240-BL(TPE2_F) 1 2211406
PCB1
Q5012 TR 2SC2240-BL(TPE2_F) 1 2211406
PCB1
Q5013 TR 2SC2240-BL(TPE2_F) 1 2211406
PCB1
Q5014 TR 2SC2240-BL(TPE2_F) 1 2211406
PCB1
Q5015 TR 2SC2240-BL(TPE2_F) 1 2211406
PCB1
Q5016 TR 2SC2240-BL(TPE2_F) 1 2211406
PCB1
Q5030 TR 2SA949-Y(TPE6_F) 1 2211354
