Eurocode Digi50 Controller V1.03 04/07/2005 Page - 32 -
EUROCODE MECHANICAL PARTS LIST
(continued)
ITEM
DESCRIPTION STOCK REF QTY NOTES
58 Roller ROL620018 6
59 Grub screw 1 M4x5
60 Main body N/A 1
61 Piston PIS620020 1 Piston/Seal assy ref. PIS620200
62 Bottom cap N/A 1
63 Databox packing PAC190028 1
64 Guide pin PIN620022 1
65 Washer WAS620065 1
66 Needle Bearing BEA521008 1
67 Spindle SPI620059 1
68 Spring SPR530033 1 Part of Spring Set.
69 Cam CAM620025 1
70 Mounting plate PLA620026 1
71 Lock nut NUT620027 1
72/73 Foil adjusting screw assy ADJ620207 1 Includes item 91.
74 Dowel pin 2 3 dia x 10
75 Plug housing HOU130023 1
76 Drive spindle SPI620029 1
77 Strike plunger PLU620036 1
78 Timing pulley PUL620030 1
79 "O" ring O-R512005 1 Part of Seal Kit.
80 Rod seal SEA512038 2 Part of Seal Kit.
81 Microswitch support SUP620031 1
82 Nose bearing BEA620070
83 Piston seal SEA512036 1 Part of Seal Kit.
84 Bush BEA520017 1
85 Microswitch SWI395010 1
86 Clutch Bearing BEA521507 1
87 Needle bearing BEA521001 1
88 Cap screw 2 M4x30
89 "O" ring O-R512030 1 Part of Seal Kit.
90 Timing belt BEL522512 1
91 Roll pin 1 3 dia x 20
92 Cap screw 4 M6x20
93 Grub screw 1 M5x8
94 Button screw 10 M4x8
95 Lock nut 1 M10
96
97
98
99 Needle bearing BEA520018 1
100 Dowel pin 1
101 Cap screw 2 M3x25
102 Cap screw 4 M4x45
103 Cheese head screw 2 M2x10
104
105 Grub screw 1 M8x8
106 CSK screw 2 M3x6
107 Side locator SID120014 2
108 Cushion DAM120074 2
109 Location pin LOC620032 2
110 lever LEV620110 1
111 Timing pulley assy PUL620219 1 Includes item 86.
112 Magnet MAG531001 1
113 Roller N/A 1 Part of item 121.
114 Insulating plate INS120012 1
115 Heater block HEA120013 1
116
117 Mounting screw SCR120070 2
118 Keep plate KEE120030 1
119 Button screw 4 M5x8
120 Cover COV620034 1
121 Fork end assy FOR620208 1 Includes items 100,113.
122 Cap screw 1 M4x12
