Open Date EUROCODE 150 - Page 33

Eurocode Digi50 Controller V1.03 04/07/2005 Page - 33 -
EUROCODE MECHANICAL PARTS LIST
(continued)
ITEM DESCRIPTION STOCK REF QTY NOTES
123 Bearing BEA620064 1
124 Bush BUS620035 1
125 Keep plate CAT620125 1
126 CSK screw 3 M4x10
127 Thumb plate THU620127 1
128
129 Locking plate LOC620129 1
130 Cap screw 2 M4x20
131 Spring SPR530032 1 Part of Spring Set.
132 Grub screw 1 M3x8
133 Plug PLG620037 2
SUPPLEMENTARY LIST FOR EUROCODE 300 ITEMS ONLY.
ITEM DESCRIPTION STOCK REF QTY NOTES
2c Rewind hub assy HUB620203 1 Includes items 42,44,50,54,148,149.
135 Magazine Plate N/A 1
136 Foil Guide GUI620040 1
137 Drive Belt DRI620049 1 Part of Spring Set.
138 Brake Strap BRA620051 1
147 Hub Spindle SPI620147 1
148 Clutch Bearing BEA521505 1
149 Drive Boss DRI620149 1
SUPPLEMENTARY LIST FOR EUROCODE 180 ITEMS ONLY
.
ITEM DESCRIPTION STOCK REF QTY NOTES
25 Drive Belt DRI620048 1 Part of Spring Set.
150 Magazine Plate N/A 1
ADDITIONAL SPARE PARTS AND REPAIR KITS
PNEUMATIC
STOCK REF
Solenoid valve without fittings. VAL510524
ELECTRONIC
Cartridge heater, 240v, 250w. HEA501506
Thermistor probe. THE500502
Safety microswitch. SWI395011
"End of foil alarm" sensor. ALA395018
Plug-in Digi50 control card, 240v, box mount (horizontal). CPC293502
Plug-in Digi50 control card, 115v, box mount (horizontal). CPC293503
REPAIR KITS
Seal kit containing all seals. SEA620209
Spring set containing all springs and drive belt (Eurocode 150). SPR620216
Spring set containing all springs and drive belt (Eurocode 300). SPR620217
Spring set containing all springs and drive belt (Eurocode 180). SPR620215
