Eurocode Digi50 Controller V1.03 04/07/2005 Page - 13 -
EUROCODE INTERCONNECTION DETAILS
CONTROL UNIT
REAR ELECTRONIC
SIGNAL
TRIGGER/PRINT
NYLON TUBING
NYLON TUBING
8mm NYLON TUBING
AIR SUPPLY, 4/6 BAR
SUPPLY
MAINS VOLTAGE
VALVE ASSY
SOLENOID
6mm "BLACK"
6mm "RED"
(Plan View)
EUROCODE PRINTER
