EUROCODE PARTS LIST
MECHANICAL
Item numbers refer to those on the assembly drawings. When ordering spare parts
please use the Stock Reference.
ITEM DESCRIPTION STOCK REF QTY NOTES
1 Magazine plate N/A 1
2a Take-off hub assy HUB620201 1 Includes items 26,44,50,56,57.
2b Rewind hub assy HUB620202 1 Includes items 26,42,44,50,54,55
See supplementary list for Eurocode 300.
3 Hub spindle SPI620003 2
See supplementary list for Eurocode 300.
4 Door assy DOO620203 1 Includes items 52,74,112.
5 Roller spindle SPI620005 6
6 Anchor ANC190006 1
7 Foil guide GUI620006 1
See supplementary list for Eurocode 300.
8 Bush BUS190008 2
9 Drive roller spindle SPI620007 1
10 Dancing bar DAN620008 1
11 Roller ROL620009 1
12 Bush BUS190012 1
13 Drive roller assy DRI620204 1 Includes items 15,22,32,33,45.
14 Dancing arm ARM620011 1
15 Pulley PUL190015 1
16 Spring post SPR190016 2
17 Spring post SPR190017 1
18 Yoke YOK620012 1
19 Spindle SPI620013 1
20 Pinch roller assy PIN620205 1 Includes item 28.
21 Pinch roller spindle SPI620015 1
22 Washer WAS620016 1
23 Spacer SPA120042 1
24 Support SUP190024 2
25 Drive belt DRI110022 1 Part of Spring Set.
See supplementary list for EC 300 & 180.
26 Bearing BEA520003 6
See supplementary list for Eurocode 300.
27 Brake strap BRA620038 1
See supplementary list for Eurocode 300.
28 Bearing BEA521006 2
29 Handle HAN530502 1
30 Grub screw 1 M5x6
31 Circlip CLI530024 2
32 Seal SEA512034 1 Part of Seal Kit.
33 Clutch bearing BEA521504 2
34 Spring SPR530034 1 Part of Spring Set
35 Spring SPR530035 1 Part of Spring Set.
36 Grub screw 2 M4x4
37 CSK screw 1 M4x20
38 Button screw 7 M4x8
39 Spring SPR530008 1 Part of Spring Set.
40 Dowel pin 1 6 dia x 28
41 Button screw 4 M5x20
42 Pan head screw 2 No.2-56 x 1/4"
43 CSK screw 2 M4x25
44 Pan head screw 4 No.2-56 x 1/8"
45 CSK screw 1 M4x8
46 Grub screw 1 M3x6
47 Button screw 1 M3x6
48 Washer 1 M3
49 Cylinder liner LIN620017 1
50 Spring clip SPR530001 2 Part of Spring Set.
51 Washer WAS120035 8
52 Hinge block HIN122006 1
53 Handle HAN120079 2
54 Back disc DIS121009 1
55 Drive boss DRI120052 1
See supplementary list for Eurocode 300.
56 Back disc DIS121008 1
57 Brake hub BRA120063 1
