Tableau Forensic Universal Bridge T356789iu
The Information Company 7
The image below is a top view of the R2 PCB assembly, which identifies these two
components. The component labeled as (1) is the processor/heatsink/fan assembly. This
component has not been moved in the new R2 design. The component labeled as (2) is
the SAS host controller FPGA. This component is located slightly more toward the front
of the bridge and to the left than the previous version. Please analyze your forensic
system with the new R2 design to ensure these components have as much free air space
above and around them as possible to help ensure proper bridge operation.
4 Other considerations
4.1 Storage media supported
The Universal Bridge supports write-blocked acquisitions of up to nine different types of
storage media.
One PCIe custom data+power connector (to be used with Tableau
PCIe adapters)
