Configuration for Monitor 2 has been completed at this time. If the other monitors were
to be configured, they could be selected at this time. For this example, the user is going to
just exit after editing Monitor 2.
Unit: Top line displays: “Using the and buttons to scroll through options, then press
the MODE button.”
Second line displays: “Monitors”.
User: Press MODE to configure another monitor, or edit an existing monitor or use the
and buttons to scroll to “Exit ”, then press the MODE button.
Unit: Top line displays “Save Changes?” and the bottom line displays “Yes= No= ”.
User: Press , thus saving the changes.
4 INTERFACE PIN ASSIGNMENTS
All connectors are dual row headers, unless otherwise noted and are numbered as
follows:
4.1 Connector: GPIB (IEEE-488) Connector
The GPIB connector is located on the rear panel of the amplifier. This should work
directly with an IDC GPIB-4882 connector. The pin assignments are:
1 - DIO1
2 - DIO5
3 - DIO2
4 - DIO6
5 - DIO3
6 - DIO7
7 - DIO4
8 - DIO8
9 - EOI
10 - REN
11 - DAV
12 - GND
13 - RFD
14 - GND
15 - DAC
16 - GND
17 - IFC
18 - GND
19 - SRQ
20 - GND
21 - ATN
22 - GND
23 - GND
24 - GND
