Table 3. Run Mode Status Displays
Menu Item
Options
Comments
Output Level Set
Fwd Pwr: XX.X dBm
Set VVA: XXX.X %
or
Fwd Pwr: XXX.X W
Set VVA: XXX.X %
(if amplifier is in VVA mode,
i.e. ‘GAIN’ LED is
illuminated).
Change Output Level using the
and keys on the front panel.
Fwd Pwr: XX.X dBm
Set ALC: XX.X dBm
or
Fwd Pwr: XXXX.X W
Set ALC: XXXX.X W
(if amplifier is in ALC mode,
i.e. ‘ALC’ LED is illuminated).
Units are in dBm or Watts
depending on Startup Options
setting selected in User
Configuration Mode (see next
section).
Change Output Level using the
and keys on the front panel.
Output Power
(Read Only in Run Mode)
Fwd Pwr: XX.X dBm
Rev Pwr: XX.X dBm
or
Fwd Pwr: XXXX.X W
Rev Pwr: XXXX.X W
Units are in dBm or Watts
depending on Startup Options
setting selected in User
Configuration Mode (see next
section).
The forward and reverse power
levels are displayed.
Input Power
(if option installed and
configured)
In Pwr: XX.X dBm
Max Pwr: XX.X dBm
Maximum Forward
and Reverse Power
Settings
Max Fwd: XX.X dBm
Max Rev: XX.X dBm
or
Max Fwd: XXXX.X W
Max Rev: XXXX.X W
These values are set at the Factory
and cannot be changed without the
Factory Jumper. These values are
set by an Ophir RF Technician for
safety purposes to protect the
amplifier. If either setting is
exceeded, a fault is generated.
