Appendix A
This Document contains proprietary and confidential information of Ophir RF Inc.
March 28, 2023 Rev: H
9
Menu Item
Options
Comments
VSWR Alarm
(Read Only in Run Mode)
VSWR Alarm: XX.X dB
The VSWR Alarm Threshold
represents the difference between the
forward power and the reflected
power (in dBm). A higher value
here represents a configuration that
is more sensitive to VSWR.
Gain (VVA) Level
(Read Only in Run Mode)
Gain: XXX.X%
When the unit is in ALC mode this
value will change dynamically as the
input signal changes.
When the unit is in VVA mode this
value should mirror the value set in
the Output Level Set display.
User can change either VVA or ALC
level by using the  and  keys on
the panel after first pushing the
‘ALC’ or ‘GAIN’ buttons.
Monitors
(Read Only in Run Mode)
I1: X.X I2: X.X
I3: X.X I4: X.X
or
V1: X.X V2: X.X
V3: X.X V4: X.X
or
T1: X.X T2: X.X
T3: X.X T4: X.X
Any combination of T, V and I
monitors are possible.
Displays the Temperature, voltage
and/or current monitors. They are
displayed four at a time; pressing the
mode button advances to the next set
of four. After all of the monitors are
displayed, pressing the mode button
advances it to the next display. If no
monitors are configured, this mode
is skipped.
GPIB Address
(Read Only in Run Mode)
Address = XX
Where
XX = 1 to 31
Default is 5
Displays the GPIB / IEEE-488
device address of the Amplifier.
Valid address values are from 1 to
31.
This menu item will not appear if the
GPIB Interface has been disabled in
the System Calibration Options.
Version
X.YY
Where
X = Revision number, and
YY = Version number
Displays the Revision and Version
number of the Front Panel Controller
firmware.
Fault Display
Temp and/or Fwd Pwr
and/or Rev Pwr
and/or In Pwr
and/or VSWR and/or Mon x
and/or ALC Range
and/or EXT. VSWR
Displays any acknowledged
notification faults. If no minor faults
have occurred, these items will not
displayed and this menu item is
skipped.
