Type of Fuel and Fuel Water Content Fuel Wood, H
2
O max. 20%
Fuel Size
25 cm 25 cm 30 cm 30 cm
Note
Fuel consumption directly depends on the quality and type of fuel used as well on the
operator’s keeping the internal heat exchange boiler surfaces clean.
6. List of Replaceable Spare Parts
Spare Parts List Spare Part Position in Fig.2
1) Stoking door 15
2) Cleaning door 16
3) Ash pan door 17
4) Inclined alloy grate 20
5) Movable alloy grate 19
6) Cleaning flap 5
7) Heating flap 4
8) Grating mechanism 2
9) Ash pan drawer 10
10) Front cover 33
11) Lateral left/right cover 34
12) Spatula and hook for cleaning boiler surface
13) Brush (holder +steel brush)
14) Thermometer 84
15) Pressure gauge 89
16) Automatic combustion air controller 41
17) Filling cock
18) Stoking door handle 27
19) Fibrous sealing 85
