Opop H 430 - Main Dimensions

Heat and Comfort
5
4. Main Dimensions Table relating to Fig. 2
H 412 H 418 H 424 H 430
A – Total Boiler Height 865 865 865 1005
B – Total Boiler Depth 598 670 670 670
C – Boiler Width 386 386 490 490
D – Location of the Gas Flue 635 635 635 755
E – Location of the Supply Water
Sleeve
99 99 99 99
F – Location of the water supply
sleeve
781 781 781 921
G – Flange Size 116 116 116 116
H – Flange Screw Spacing 67 67 67 67
J – Boiler Base Depth 398 470 470 470
K – Boiler Base Width 316 316 420 420
