Duct Smoke Detector KRM
4 | 9 | Fire Protection | Data sheet No. 41300 | Version 06-2012
Behavior of the alarm relay and fault relay and displays, plus reset options
Installation instructions and positioning
The KRM is to be positioned in accordance with the current
local state regulations on ventilation systems. Reliable smoke
detection must be guaranteed. Depending on the cross section
of the ventilation duct the air collecting tube may be cut to a
length of 160 mm. This minimum length of 160 mm must not
be undercut. This way, up to <100 mm ø can be monitored in
conjunction with the KS mounting bracket. With respect to the
maximum width/ maximum height/ maximum diameter of the
air ventilation ducts to be monitored with the 600 mm long
standard air collecting tube, there are no limitations according to
the VdS approval / DIBt certication. The airow direction must
be observed during the installation of the air collecting adapter.
The air collecting tube may be mounted laterally below or above
the air duct – the location is arbitrary.
LEDs Meaning Comments
Alarm / reset
(red)
Smoke alarm
or failure
Reset after failure:
Briey press alarm / reset button. KRM immediately restarts.
Reset after alarm:
Press and hold the alarm / reset button for at least 2 seconds until the red alarm LED in the
button goes out. Do not release it until then. KRM will start again only after release. As long as
the alarm / reset LED ashes when the button is pressed, the smoke sensor is still lled with test
gas / test spray / smoke, and can not be reset. In that case blow the sensor out or wait.
Failure
(yellow)
Defective circuit
board or missing
smoke alarm
Check / replace circuit board or smoke detector RM 3.3 (ALK-E).
Smoke alarm
(2 x red)
Smoke alarm
or contamination
99 %
Red LEDs directly on the smoke detector RM 3.3 (ALK-E). LEDs permanently on until reset has
taken place.
Power
(green)
Supply voltage
is on
Green LED lights up if supply voltage is on.
Air ow
(blue)
Air ow is too
low
Blue LED lights up when air ow is too low and air relay (only equipped on DIBt versions) drops
out. Check smoke detector position in the duct, check sampling tube (TurboTube) for contami-
nation / clean if necessary.
Valid with soft-
ware 0020
Smoke alarm Device failure / missing detector…
DIBt versions
KRM-1-DZ / KRM-2-DZ
KRM-2-DZ-MOD
KRM-1 / KRM-2
KRM-2-MOD
DIBt versions
KRM-1-DZ / KRM-2-DZ
KRM-2-DZ-MOD
KRM-1 / KRM-2
KRM-2-MOD
Alarm relay
11 / 12 / 13
Drops out Drops out Drops out Drops out
Relais Alarm
14 / 15
Drops out Drops out Drops out Drops out
LED
Alarm / Reset
Lights up Lights up Lights up Lights up
Relay failure
18 / 19
Does not drop out
---------
Not equipped
Drops out
---------
Not equipped
LED failure Does not light up Does not light up Lights up Lights up
Alarm reset or
failure reset
Not with power
interruption!
It is mandatory to use
the alarm button or ter-
minal 9 / 10 provided that
sensing chamber is free.
With power interruption,
alarm button or with
terminal 9 / 10 provided
that sensing chamber
is free.
Not with power
interruption!
It is mandatory to use
the alarm button or ter-
minal 9 / 10 provided that
sensing chamber is free +
disturbance has ceased.
With power interruption,
alarm button or with
terminal 9 / 10 provided
that sensing chamber
is free + disturbance has
ceased.
