INSTALLATION
Decide where to locate the light
strips and ensure wiring has enough
length for control box to be installed
in desired location.
STEP 1
Once connected, plug the control box Cigarette Power Adapter into an available
12 volt charging port.
CIGARETTE POWER ADAPTER12 VOLT CHARGING PORT
1.
2.
Connecting to more than 10 AMP will override the kit and cause early failure,
ensure it is 10AMPs or less!!
Please ensure that the LED bars or strips/control box/wiring all are mounted
in areas where will not exceed 85℃ or 185℉.
WARNING
As shown below, connect all light strips to the control box with the included
extension cables.
EXTENSION WIRE LIGHT STRIP
