INSTALLATION
Thoroughly clean the surface where you plan
on mounting the LED strip with rubbing /
isopropyl alcohol. (This part is essential for a
rm and long lasting placement.
A dirty surface will prevent the strip from attaching firmly. Peal the double-sided tape and
firmly press the LED strip to the mounting area and hold for 3 seconds. Then, use the
zip-ties to tie all the wirings away from all moving components.
STEP 2
STEP 3
Secure Control box in desired location
with Velcro or zip ties.
* CONTROL BOX NOT WATERPROOF
Ensure the control box is safely and securely hidden from
exposing elements of moisture.
Note the
direction of
the arrows
BE SURE TO CONFIRM THE CORRECT DIRECTION OF THE ARROW!!
TO AVOID PRODUCT DAMAGE DUE TO INCORRECT INSTALLATION.
CORRECT INSTALLATION
IMPORTANT
! !
Flow direction
To Next Page
