Decide where to locate the light strips and
ensure wiring has enough length for control box
to be installed in desired location.
STEP 2
EXTENSION WIRE Y-SPLITTER LIGHT STRIP
IMPORTANT:
The control box must be installed inside the
vehicle as it is not waterproof. Avoid installation
areas of the engine bay + heated surfaces.
INSTALLATION
Inspect kit to ensure all contents was included.
STEP 1
EXAMPLES
AUXILIARY WIRE
EXTENSION WIRE(10FT)
R
L
FR
BR
FL
BL
EXTENSION WIRE(10FT)
Y-SPLITTERS
Y-SPLITTERS
1.
2.
Connecting to more than 10 AMP will override the kit and cause early failure,
ensure it is 10AMPs or less!!
Please ensure that the LED bars or strips/control box/wiring all are mounted
in areas where will not exceed 85℃ or 185℉.
WARNING
