Please ensure the Underglow LED Bars / Control Box / Wirings are all
mounted away from heated surfaces exceeding from 85°C or 185°F.
WARNING
EXAMPLES
FUSE
AUXILIARY WIRE
TM
HOW TO CONNECT
POWER HARNESS TO
YOUR VEHICLE
Connect the Red wire (+) of power
harness to the vehicle battery's
positive terminal.
Connect the Black wire (-) of power
harness to the vehicle battery's
negative terminal or an unpainted
area on your vehicle's frame.
-
-
1 x 36” (two-section movable 18") LED Bar + 8ft extension wire
1 x 36” (two-section movable 18") LED Bar + 18ft extension wire
1 x 48” (two-section movable 24") LED Bar + 8ft extension wire
1 x 36” (two-section movable 18") LED Bar + 18ft extension wire
1 x 48” (two-section movable 24") LED Bar + 8ft extension wire
1 x 36” (two-section movable 18") LED Bar + 18ft extension wire
The extension wires are on the led bar.
Lay out the bars to measure the length prior to install for
a successful installation.
