Function List
To change the settings, press the ENTER button for three seconds or more.
The settable items are shown below.
Change the settings as necessary.
While the indication fl ashes, the settings are being read or written and the button operation
is not accepted.
No. Indication Name Descriptions Page
(1)
BANK
Bank Select the bank (1 to 4) to change the setting.
12
Individual setting is possible for each of 1 to 4 banks. Switching the
bank by cable connection can call up the saved setting.
(2)
DELY
Delay Select the response time.
12
The response time changes as you change the number of moving
average times. The response time is delayed more as you increase the
number, which is effective to minimize fl uctuation of measurement values.
(3)
TADJ
T-Adjust
Make the temperature measurement settings such
as emissivity rate.
12
You can change the emissivity rate and make simple temperature
adjustment.
(4)
ASCL
Analog Scale
Change the output temperature width of analog
output.
15
You can specify a desired measurement width for analog output (4-
20mA) within the measurement temperature range.
(5)
ALAM
Alarm Make the contact output settings.
16
You can select ON/OFF, type and temperature for alarm output.
(6)
TRLG
Trigger Make the trigger input settings.
18
You can specify the type of trigger input as a switch to execute output
control.
(7)
ECO
ECO Set the ECO mode.
21
You can set the ECO mode in order to reduce current consumption by
turning off the display of main unit.
(8)
END
End Save the modifi ed settings.
21
You can save the Setting values in the bank or switch to the next bank
to change the setting.
* The values confi rmed with SET will be deleted if they are not saved
in this mode.
If the unit is left unoperated for ten seconds or more, it returns to the measurement mode. At
the time, the settings not saved by END -> SET will be deleted.
