External Dimensions/Parts Name
Lens surface
φ
7
M12 × P1.0
10
30
φ14
Sensor head
Sensor cable
φ
4×3000 (MAX)
Cable cover
Serial No.
▲/▼
buttons
ENT. button
Output cable
φ
6×2000 (MAX)
Cable No.
Main display
Amplifi er
Sub display
64
52
35
38.5
31
[mm]
DIN rail attachment part
Cable No.
φ10
4
