16
Setup of Functions
●
ALAM
：
ALAM/ Alarm (contact) output mode
ALAM
400
You can set the temperature and output method of
alarm (contact)output.
H (upper limit value): Output turns on when the value
exceeds the Setting value.
L (lower limit value): Output turns on when the value
falls below the Setting value.
Select one of the three types of OUT (output) mode:
NOR, DEL and ONES.
ALAM
50
OUT
NOR
OUT
DEL
OUT
ONES
NOR
DEL
ONES
L
ON
OFF
H
L
ON
OFF
H
t
L
ON
OFF
H
t
t: Time to delay output
t: Time to keep output on
ONES: Output turns on when the value exceeds or falls
below the set temperature and is kept for a specifi c time.
NOR: Output is kept on as long as the value is over or below
the set temperature.
DEL: Output turns on when a specifi c time period passes
after the value exceeds or falls below the set temperature.
Measurement value
Measurement value
Measurement value
Contact output
Contact output
Contact output
