4
Accessories: Mounting nut (M12 × P1.0) × 2
Options: Black body tape, mounting fi tting, amplifi er protective case, changeable laser marker, air purge
collar, CF lens
* The specifi cations are subject to change without notice for product improvement.
Specifi cations
Model
CS-30TAC-HT CS-40TAC-HT
CS-30TAC CS-40TAC
Temperature range 0 °C to 1000 °C -40 °C to 500 °C
Area size
φ
30/500 mm
22:1
φ
40/500 mm
15:1
φ
30/500 mm
22:1
φ
40/500 mm
15:1
Optics Silicon lens(Water-repellent coat, Oil-repellent coat)
Detection element /
Wavelength
Thermopile/ 8 to 14 μm
Response speed 150 msec/90
％
Accuracy
0 to 200
°
C: ± 2
°
C
201 to 1000
°
C: Reading value ± 1 %
-40 to 0
°
C: ± 3
°
C
1 to 200
°
C: ± 2
°
C
201 to 500
°
C: Reading value ± 1 %
Repeatability
Up to 200
°
C: ± 1.0
°
C
201
°
C and more
：
± 0.5 %
Emissivity rate
adjustment
0.1 to 1.2
Power supply 12 to 24 VDC ± 10 %
Consumption 120 mA (Max. load), 80 mA (Eco mode)
Ambient temperature
Sensor head: 0 to 180°C, Amplifi er: 0 to 65°C Sensor head: 0 to 100°C, Amplifi er: 0 to 65°C
Ambient humidity 35 to 85 % (without condensation)
Storage temperature 0 to 70
°
C
Water resistance Sensor head: IP69K, Amplifi er: IP40
Vibration resistance 10 to 55 Hz, 1.5 mm amplitude, 2 hours each for XYZ directions
Material Sensor head: SUS, Amplifi er: ABS
Dimensions Sensor head: M12 (
φ
14) x 34 mm, Amplifi er: 35 x 52 x 38.5 mm
Weight
Sensor head: Approx. 100 g (including a cable of 3 m),
Amplifi er: Approx. 200 g (including a cable of 2 m)
Display LED
Resolution 1°C
Analog output 4 to 20 mA
Analog output resolution
0.5°C
Analog output accuracy
± 0.5% or ± 1.0°C
Analog output updating time
10msec
Analog output allowable load
250 Ω
Analog output impedance
47 Ω
Contact output Photo MOS FET x 2
(c contact x 2)
Contact output capacity
300 mA/ 30 VDC or less
Interface Digital output
Others
Trigger (synchronous) input
Bank switch x 4
