First, the panel at the left side near the manometer should be removed to make the various electrical connec-
tions.
A ve-core cable, automatic moisture meter, remote control and temperature sensor are supplied with the unit.
Their cables can be led to the outside through the opening at the bottom of the panel. The power cable for the
power supply can be led through the black feed-through rubber at the side of the unit.
Automatic moisture meter,
remote Control, power supply
for clock, temperature sensor,
ve-core cable
ELECTRICAL CONNECTIONS
Power cord
