BIOLINE Manual for installation and use
OPTIKON 2000
by the following wording on the screen: RUN X and STOP X respectively, with
X from 1 to 5
Activation starts up a series of 5 measurements interspersed by a brief pause.
After the acquisition of the fifth measurement a dual tone indicates that the
series of measurements has been completed.
• ARROWS <— and —>: The 5 memories available for biometric
measurements are brought up in succession. (The measurement is
automatically saved when it is taken).
• IOL: Forwards to the lens calculation session. The axial length obtained from
the average of the measurements (indicated by AVG) is automatically sent on
to the calculation page.
• SET: Allows certain configuration parameters to be reset. The configuration
menu allows either cancellation of all the data stored about the lenses, or
selection of the language (English or Italian) for any printing out of the rapid
user guide.
• D-BASE: Forwards to the archiving session if the connection with an external
personal computer is present (via port RS232). If the connection is not
present, the autotest page is displayed.
• PRINT: Starts up the printing of the graph and the biometry results. If several
measurements are displayed the one closest to the average is displayed and
sent to be printed.
8.4 SETTING UP THE A-SCAN EXAMINATION
The operating parameters (EYE, MODE, GAIN, PRMT) indicated at the bottom left of
the screen, can be displayed one at a time and modified as follows:
1. Press the ENTER key or the vertical arrows; in this way one parameter for the
input is displayed.
2. Now press the up-down arrows again to move to the desired parameter. Use
the left-right arrows to change the value of the parameter.
3. Finally press the Enter key to close the input and return to operating mode.
The parameters of the A-SCAN session are as follows:
• EYE : Specify OS-REF, OD-REF, OS, OD, to indicate, respectively,
reference Left Eye and reference Right Eye, Left Eye (principal), Right
Eye (principal). The selection of a reference eye prior to examining the
Code 141002EN 8-3 26.10.05 Rev.0
