Version 1.0.4 dated 2015-11-19 Page 27Original operating instructions
DRO 5 GB
5.9 Compatibility with other OPTIMUM digital displays
Using of your currently installed measuring system on the machine with the digital display DRO5.
5.10 Operating manual change information
Display Compatible Anzeige Compatible
MPA3 - DRO5 no Read head different,
magnetic stripe differ-
ently
DPA21 - DRO5 no Connector differ-
ently = active
read head
MPA4 - DRO5 no Read head different,
magnetic stripe differ-
ently
DPA22 - DRO5 no Connector differ-
ently = active
read head
DRO3 - DRO5 no Connector differently
= active read head
DPM1 - DRO5 no other system
DPA2000 - DRO5 no Connector differently
= active read head
DPM3 - DRO5 no other system
DPA2000S - DRO5 no Connector differently
= active read head
Chapter Short note New version no.
all Page layout columns in one column 1.0.1
5.4.1 Drawings sketches of mounting examples 1.0.2
2.2 Optionally available 1.0.3
5.1.3 Parameter setting for reading head MS200 (MR000) 1.0.3
5.9 Compatibility with older digital displays 1.0.3
3.3 6-pin socket, connection 1.0.4
