2 Technical specification
The following information represents the dimensions and indications of weight and the manufacturer‘s approved machine data for following stated
machines.
Noise emission values
The A-evaluated noise level of the magnetic drill at a one metre distance is 66 dB(A) to 69 dB(A). The sound power level is less than 85 dB(A).
This numerical value was measured on a new machine under the operating conditions specified by the manufacturer. The noise behaviour of the machine
might change depending on the age and wear of the machine.
Furthermore, the noise emission also depends on production engineering factors, e.g. speed, material and clamping conditions.
Machine designation
DM35 DM35V DM35PF DM36VT DM38VF DM50 DM50V DM50PM DM60V DM98V
Electrical connection
230V ~50 Hz ( optional ~60 Hz ) [ optional 110V ]
Drive motor power
Input power [ kW ] 1.6 1.55 1.6 1.55 1.65 1.75 1.7 1.7 1.89 2.18
permissible operating mode 50 % S2 duty cycle 240 minutes
Protection class IP 42
Drill diameter
Core drill maximum [ mm ] Ø 35 Ø 35 Ø 35 Ø 36 Ø 38 Ø 50 Ø 50 Ø 50 Ø 68 Ø 98
Twist drill maximum [ mm ] Ø 13 Ø 13 - Ø 18 - Ø 13 Ø 13 Ø 13 Ø 23 Ø 28
Screw tap maximum [ mm ] - - - M15 - - - - - -
Max. drilling depth / core drills [ mm ] 35 35 35 35 35 50 50 50 50 75
Magnet
Magnetic holding force [ kN ] 13.8 14.8 16 14.2 14.5 14.5 15.6 16.5 16 17
Dimension [ mm ] 166 x 80 166 x 80 166 x 80 166 x 80 156 x 80 166 x 80 166 x 80 165 x 83 202 x 103 202 x 103
Machine weight
[ kg ] 10.5 10.8 14 12 8.8 10.6 11 11.7 18.3 18.5
Spindle speed under load
approximately [ rpm ] 810 120 - 830 810 15-270/520 670 790 100 - 810
20-280 /
510
100 - 470 160-340
-
infinitely
variable
-
infinitely
variable
--
infinitely
variable
2 stages,
gearbox
infinitely
variable
infinitely
variable
Spindle seat
Weldon 3/4"
MT2
Weldon 3/4"
MT2 +
Weldon 3/4"
MT3 +
Weldon 3/4"
Tool shaft
Weldon shaft Ø 19 mm (3/4”) Weldon shaft Ø 19 mm (3/4”)
