8
• Always plug the adapter into the recorder before you
plug it into the AC outlet. Always unplug the adapter
from the AC outlet before you unplug it from the
recorder.
1. Set the adapter’s voltage switch to 3V.
2. Attach the 3.4 mm outer diameter/1.3 mm inner
diameter barrel plug to the AC adapter’s cord with the
tip set to negative (–).
3. Insert the barrel plug into the recorder’s
DC 3V
jack.
4. Plug the adapter into a standard AC outlet.
Using DC Power
To power the recorder from your vehicle’s cigarette-lighter
socket, you need a DC adapter (not supplied), such as
Cat. No. 273-1810 or Cat. No. 270-1560.
Illust.
