5. CONFIGURATION
The configuration defines the mode in which we communicate with the module by means of DTMF tones
of a telephone call. Access to this configuration is gained by pressing the “CONFIG.” button on the
module and making a call through the telephone connection. Once the module answers, 10 digits must
be entered. Each digit configures a different parameter.
5.1. CONFIGURATION PARAMETERS
The programmable parameters are:
Digit / Parameter
Description
Values
1
First digit of the password
0 to 9
2
Second digit of the password
0 to 9
3
Third digit of the password
0 to 9
4
Number of call tones before module answers
1 to 9
5
Parameter not used
0 to 9
6
Parameter not used
0 to 9
7
Parameter not used
0 to 9
8
Hang-up tone detection time
0 to 9
9
Noise gate (0, deactivated / 1, activated)
0 to 1
10
Maximum message time
0 to 9
Parameters 5, 6 and 7 are not used and any number key can be pressed.
PARAMETERS 1, 2 and 3: PASSWORD
These establish the three digits of the password:
P1
P2
P3
DESCRIPTION
0
0
0
Without password: the call is made and the module answers after the dial tones configured.
X
X
X
The password is X X X: the call is made, the module answers and the password must be keyed in from
the telephone.
If the password is correct, three tones will be heard and the message can be broadcast.
PARAMETER 4: CALL TONES
This configures the number of call tones after which the module will answer when a call is made to
broadcast a message (between 1 and 9).
N.B.: In the case of the configuration call, the module always answers after two call tones.
PARAMETER 5: Parameter not used.
Press any number key.
PARAMETER 6: Parameter not used.
Press any number key.
PARAMETER 7: Parameter not used.
Press any number key.
