Optimus M130 - M134 P Technical Specifications; M134 P Electrical and General Specs

M130 Version 1.0 Page 18 of 23
M130
8x8 Audio Matrix
7. TECHNICAL SPECIFICATIONS OF M134P
Electrical Specifications:
Microphone Input
-50 dB Balanced
Line input
-20 dB Unbalanced
Audio out
0 dB Balanced
RS-422 Interface
Communication speed 19.200 bps
Full Duplex, Multi-Drop methods, Data 8 bits, Stop 1 bit, Start 1 bit, non parity.
Maximum communication distance: 1.000 m, using CAT5 UTP.
Signal to Noise Ratio (SNR)
> 90 dB
THD
< 0,01 % a 100 Hz ~ 10 kHz
0 dB = 1 Vrms
General Specifications:
Power Source
24 VDC
Power Consumption
< 5 W
Weight
0,6 kg
Dimensions
86 (W) x 172 (H) x 43 (D) mm
Temperature / Humidity
0 ~ 40ºC / < 95 %
Specifications can be changed without notice.
