CONTENTS
INSTALLATION MANUAL FOR OPTIMUS 4G LTE RANGE OF INTERCOM UNITS
Applicable Products 03
GENERAL 04
Overview 04
How it works 04
Product Description and Dimensions 04 – 05
INSTALLATION AND CONNECTION 06
Special Tools and Materials needed 06
What’s Inside The Box 06
Positioning and Mounting the Intercom Unit 07
Surface Mounting 07
Siting of the Antenna 08
Cable Entry and Exit 08
Power Connection and Disconnection of the Optimus Range 08
Protective Earth and Bonding Terminals 09
APPLICATIONS AND CONNECTIONS 10
4G LTE I/O Board Connections 10
4G LTE PCB Connections 10
Applications Examples 11 – 14
Installing or Replacing the SIM Card 14
PROGRAMMABLE SETTINGS VIA GSM ONE APP + ADDITIONAL 15 - 16
MANUAL SMS COMMANDS
Congurable Settings 15
INTERNAL CELL REPLACEMENT FOR REAL TIME CLOCK RTC 17
Replacing the Lithium Cell 17
EU CE DECLARATION OF CONFORMITY AND RADIO EQUIPMENT DIRECTIVE 18
