PREPARATION
Note:
Complete all connections be-
fore connecting to AC power and
turning it on.
CONNECTING THE
SPEAKERS
1. Press the red speaker terminal
tab labeled
SPEAKER R. Ch
on the back of the system, insert
the stripped end of the right
speaker’s striped wire into the
terminal, then release the tab.
2. Press the black speaker terminal
tab labeled
SPEAKER R. Ch
on the back of the system, insert
the stripped end of the right
speaker’s other wire into the ter-
minal, then release the tab.
3. Repeat Steps 1 and 2 to connect
the left speaker to
SPEAKER L.
Ch
and terminals.
CONNECTING AN
EXTERNAL AUDIO
SOURCE
To connect an external audio source
(such as a CD player or a cassette
deck) to your system, connect the
source’s left and right line level out-
put jacks to the
AUX IN R
and
L
jacks
on the back of your system.
CONNECTING AN
EXTERNAL ANTENNA
You can attach an FM or VHF anten-
na (not supplied) to the 300 ohm
EXT.
ANT.
terminals on the back of the sys-
tem.
If you have an outside VHF TV an-
tenna, you can use a signal splitter
with a 300-ohm output to connect
your stereo system and TV set to the
same antenna. Your local Radio
Shack store has a wide selection of
antennas, connectors, and splitters.
+
-
+
-
