Introduction
7
Vie
Front-right View
ws of Projector
ITEM LABEL DESCRIPTION SEE PAGE:
1.
Ventilation opening To keep the projector lamp cool
2.
Height-adjuster button justor Push to release height ad
3.
Height-adjuster
20
Adjusts level of projector
4.
Lens cap Attach to protect lens when not in use
5.
IR receiver ontrol
11
Receiver for IR signal from remote c
6.
Lens Adjust focus/zoom on top opening
7.
Focus Focuses the projected image
8.
Zoom Enlarges the projected image
21
9.
See “Top view—OSD buttons and LEDs”
8
Important:
Ventilation openings on the projector allow for good air circulation, which keeps the projector lamp
cool. Do not obstruct any of the ventilation openings.
