Optoma ES515 - Ceiling Installation Guidelines

English
63
Ceiling Installation
To prevent damage to your projector please use the recommended
mounting package for installation.
To ensure compliance, only use a UL Listed ceiling mount and
screws that meet the following speci󰘰cations:
4
Screw Type: M4
4
Maximum screw length: 8 mm
4
Minimum screw length: 6 mm
Refer to the following diagram to ceiling mount the projector.
42.50
103.0056.90
5.00
LENS
159.90
97.50
v Damage to the
projector as a
result of incorrect
installation voids
the warranty.
v Ensure at least
0cm clearance
between the
ceiling and the
underside of the
projector.
v Avoid locating the
projector near
heat sources
such as air
conditioning and
heaters. Excess
heat may cause
the projector to
power o󰘯.
