Optoma EX531 - Table of Contents

ES526/EX536/EX531/CB2800/ES526L/EX536L
Condential
III
Table of Content
Chapter 1 Introduction
Highlight 1-1
Compatible Mode 1-2
Chapter 2 Disassembly Process
Equipment Needed & Product Overview 2-1
Disassemble Lamp Cover Module 2-2
Disassemble Lamp Module 2-2
Disassemble Top Cover Module 2-3
Disassemble Keypad Board Module
(Not for ES526L/EX536L) 2-4
Disassemble Zoom Ring 2-4
Disassemble Top Shielding 2-5
Disassemble Main Board Module 2-5
Disassemble Main Board Shielding 2-7
Disassemble Front Cover Module and IR Sensor Board 2-8
Disassemble Engine Module 2-8
Disassemble Color Wheel Module 2-9
Disassemble DMD Chip and DMD Board 2-9
Disassemble Rod Module 2-10
Disassemble Focus Ring 2-10
Disassemble Fan Module 2-11
Disassemble LVPS 2-12
Disassemble IO Cover and Security Bar 2-13
Disassemble Interlock Switch 2-14
Disassemble Lamp Driver Module 2-14
