EX762/EW762
Condential VI
Item P/N Description Parts Supply
1 70.8EF09G001 IO BOARD ASSEMBLE EX612
2 80.8FB01G001 PCBA MAIN BOARD FOR EX762 V
3 80.8EF07G001 PCBA LAN MODULE BD FOR EX615/EX542 V
4 61.00080G001 STAND OFF H=6.0 M2/M3*L6 Sn EP910
5 85.1A122G040 SCREW PAN MECH M2*4 Ni
6 86.0A123G024 HEX NUT M3*5.5*0.5P L2.4 Ni
7 85.1A123G050 SCREW PAN MECH M3*5 Ni
8 61.83N19G001 HEX SPACER M3 H=17mm L=5mm AL PD726
9 80.8EF06G003 PCBA DAUGHTER BD FOR EX612 V
10 85.1A123G050 SCREW PAN MECH M3*5 Ni
ASSY MAIN BOARD AND IO BOARD MODULE
8
9
10
