4-4 Test Condition
4-4 Test Condition
4-4-1 Normal Test Condition
- Circumstance brightness: Dark room less than 10.0 lux
- Screen size: 60 inches
Screen Defects
Defect specication table
12.5 cm
12.5 cm
Zone B
Frame
Zone C
For EX762
Order Symptom Pattern Criteria
1 Bright pixel ( dots) Gray 10 pattern A+B=0
2 Dark pixel(dots) White pattern A+B≤4
3 Unstable pixel (dots) Any pattern A+B=0
4 Adjacent dark pixel (dots) Any pattern A+B=0
5 Dark blemish (Dirty) Blue 60 pattern
A+B≤2
(diameter <1/2 inch)
6 Bright blemish (Dirty) Gray 10 pattern
A+B≤2
(diameter <1/2 inch)
7 Bright dots on frame Gray 10 pattern ≤1
