PK120 Specications
Optical Specication (Panel)
Manufacturer Texas Instruments
Type DLP® 0.2 nHD DMD
Size 0.22 inches (diagonal)
Display pixels 640 x 360
Projection
image size
10” ~ 60”
Throw ratio 2.2
Horizontal
scan rate
31.5 ~ 48.4 KHz
Vertical scan rate 50 / 60 Hz
Aspect ratio 4:3, 16:9, Auto
Parameters
Internal memory 2GB NAND Flash
External memory micro SD card (up to 32 GB)
Brightness
Bright mode: 12lm
STD mode: 8lm
Luminance
Uniformity (JBMA)
50% (Minimum)
60% (Typical)
Contrast Ratio 1200:1 (Typical)
Projection Offset 100%
I/O Connectors
Universal (24-pin) to VGA IN x 1
Composite Video / Audio (Φ 2.5mm) x 1
microSD card slot x 1
Audio output (Φ 3.5mm) x 1
Micro USB x 1 (for data transfer / charging)
Input Signal Specication
Analog RGB signal
(PC)
Analog RGB 0.7 +/- 0.1 •
Vp-p, 75 ohm
Separate TTL, H, V Sync•
Video signal
NTSC / PAL Compsite video 1.0
+/- 0.1 Vp-p, 75 ohm
Audio signal
(Share with A/V input jack)
300mVrms, 22K ohm
AV-IN
Audio input: 0 ~ 1 Vrms
Video input: 0.5 ~ 1.8 Vp-p
Output Signal Specication
Micro USB X 1
(Device/Battery charge)
Host support < 150mA 5V
Audio out 3.5Ψmm jack
Speaker Built-in stereo speaker 0.5W x 2
Video Compatibility
NTSC NTSC M/J 3.58MHz, 4.43MHz
PAL PAL B/D/G/HI/M/N, 4.43MHz
SDTV 480i, 576i
RGB 480i / 480P, 576i / 576P
Computer Compatibility
VESA standards, PC & Macintosh compatible
Physical Specications
Weight 145g (with battery)
Dimensions
(L x W x H)
117 x 60 x 21 mm
Charging time 2.5 hours
Operating time
Video: 80 min (high brightness)
Music: 4.5 hours
Operating
temperature
0° ~ 30°C (32°F ~ 86°F)
Storage
temperature
-20° ~ 60°C
Humidity
10 ~ 40% RH (without condensation)
0 ~ 1829 m (0 ~ 6000 feet)
above sea level
Power Specications
Battery 3.7V, 1800mAh
Power supply 5V, 2A, 110 ~ 240V
Charging time 2.5 hours
Battery operating
temperature
Charge: 0° ~ 45°C
Discharge: -20° ~ 60°C
Specications are subject to change without prior
notice.
te c h n I c a l Sp e cI f Ic at I on
HDPY2001010
P/N 36.00040G011- B

Optoma Pico PK120 Specifications

General

Projection distance	- m
Projection technology	LED
Contrast ratio (typical)	2000:1
Screen size compatibility	40 - 70 \
Audio input	Yes
Aspect ratio	16:9
RS-232 ports	0
Network ready	No
Power supply type	AC/DC
Dimensions (WxDxH)	60 x 117 x 21 mm
Connectivity technology	Wired
Focus	Manual
Focal length range	- mm
Lamps quantity	1 lamp(s)
Service life of light source	20000 h
RMS rated power	1 W
Audio formats supported	AAC, AMR, APE, MP3, MS-ADPCM, WMA
Image formats supported	BMP, JPG
Video formats supported	3GP, ASF, AVI, H.263, H.264, M-JPEG, MOV, MPEG4, VC-1, VOB, WMV, XVID
Document formats supported	DOC, DOCX, HTML, XLS, XLSM
Number of built-in speakers	2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Compatible memory cards	SD, SDHC
Maximum memory card size	32 GB
Internal storage capacity	1 GB
Noise level	- dB
Product type	Portable projector
Product color	Black
Market positioning	Portable
Power source	AC/Battery
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Battery life (max)	1.5 h
Power consumption (standby)	- W
Cables included	AV, VGA

Weight and Dimensions

Depth	117 mm
Width	60 mm
Height	21 mm
Weight	145 g
