Optoma WU337 - Keypad

English
11
INTRODUCTION
Note:
 Remote mouse requires special remote control.
 The I/Os depend on the projector you purchased, please check the physical product for reference.
Keypad
1
2
3
6
5
4
9 8
12
11
9
7
10
No Item No Item
1. On/Standby LED 7. IR Receiver
2.
Lamp LED
8.
Enter
3. Temp LED 9. Keystone Correction
4. Information 10. Menu
5. Re-Sync 11. Source
6. Four Directional Select Keys 12 Power
