19
INSTRUCTIONS
REAR WHEEL ASSEMBLY / DISMANTLING
1/ Place the wheel in the frame, making sure the
power cable stays between the chainstay and seat
stay (g.1) for a easy connection later on.
2/ Place the anti-rotation whasers in both axle ends
and tighten the M2 nuts with an 8 Allen key at the
right torque (Min. 18Nm/ max. 25Nm.)
M12 NUT
ANTI-ROTATION WASHER
1 2 3
CONECTOR
