BLUE PAPER ONNA · 20222 | ORBEA ORBEA | 3TECHNICAL MANUAL 3
EN
INDEX
01 KEY TO SYMBOLS 4
02 ORBEA WARRANTY 6
03 MAINTENANCE 8
Components maintenance schedule 9
Spare parts 11
After a crash or an impact 11
04 USE WARNINGS 12
Maximum tire width 12
Maximum number of headset spacers 12
Headset spacers above the stem 12
Maximum fork length 13
Intended use 13
05 ONNA 2022 14
Geometry and sizing 16
Technical specications 18
Assembly, use and spares 20
Headset 20
Rear derailleur hanger 22
Other frame hardware 23
Protectors 24
Kickstand 25
Cable routing 26
Suspension adjustments 29
06 DECLARATION OF CONFORMITY 30
07 ADDITIONAL INFORMATION 31
